1.Technical Specifications
IP65/IK07-rated stainless steel housing (SUS304 standard, SUS316 optional) resists water ingress, dust intrusion, and physical impact in continuous 24/7 public operation.
Over 2-million-keystroke lifespan ensures sustained reliability in unsupervised high-traffic environments.
Integrated audible feedback confirms each entry audibly, reducing input errors in noisy surroundings; customizable backlit keys improve visibility under variable lighting conditions.
Wide-temperature tolerance from -40°C enables reliable performance in both indoor climate-controlled spaces and exposed outdoor installations.
Plug-and-play USB compatibility supports rapid deployment across Windows, macOS, Linux, Android, and embedded systems without driver installation.
2.Mechanical Features & Environmental adaptability
| Panel board and keys material |
SUS304 Stainless-steel |
| Base board |
Alumium alloy |
| Key life cycle |
2mil min |
| Key press force |
2~3N |
| Key travel length |
0.6MM |
| Dimensions |
140*95*15.5MM |
| panel size |
87.5*91.5MM |
| Weight |
245g |
| OperatingTemperature |
-40℃～+65℃ |
| Operating RH |
10～95% |
| Storage temperature |
-40℃～+75℃ |
| Storage RH |
5～95% |
Protection grade: IP65 / IK07
EMC Standards:
EN55022:1988+A1:2000+A2:2003
EN55024:1988+A1:2001+A2:2003
ESD protection: 15KV
3.Keyboard Language
Defult keyboard language is US.
Optional for customized different languages, such as Spanish, French, German, Portuguese, Italian, Russian, Arabic, Persian, etc.
4.Installation Drawing
5.Application Site
Optimized for semi-supervised and unsupervised public access points where corrosion resistance, low maintenance, and clear user feedback are essential: outdoor fuel dispenser PIN pads, transit ticket vending machines in open-air platforms, bank ATM vestibules, parking lot payment kiosks, university campus card reload stations, hotel self-check-in terminals, airport luggage locker keypads, and shopping mall directory access panels in humid or dusty environments.
6. more pictures:
8. Please note:
All photos on this website were taken in real conditions. Due to variations in lighting, shooting angles, and display resolutions, the images you see may exhibit a certain degree of color difference. We kindly ask you to refer to the actual received products for accurate representation. Thank you for your understanding.
If you have any question about this items,please feel free to contact us for further information,thank you.
