Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant

2
MOQ
negotiable
Price
Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant
Features Gallery Product Description Request A Quote
Features
Specifications
Material: SUS304 Stainless-steel
Feature: ,waterproof, Dustproofviolence Resist And Explosionproof
Colour: Silver
Keyswitch Lifespan: More Than 2 Million Of Operations
Weight: 3060g
Operating Temperature: -40℃~+65℃
Protection Level: IP67 / IK07
Language: US,Optional For Customized Different Languages
Basic Infomation
Place of Origin: China(mainland)
Certification: CE/ROHS/FCC
Model Number: F-Tp-352140
Payment & Shipping Terms
Packaging Details: negotiable
Delivery Time: 5-10 worrking days
Payment Terms: Western Union,L/C,T/T
Supply Ability: 10000 pieces per month
Product Description

Industrial Stainless-Steel Keyboard F-Tp-352140 Waterproof Dustproof Violence Resist keyboard


Technical Specifications

Full-watertight industrial stainless steel keyboard, integrated with 2-key sealed touchpad.

Certified IP67 waterproof & dustproof rating, IK07 vandal resistance, optional explosion-proof barrier.

Exceeds 2 million keystroke lifecycle under harsh conditions.

Keys and chassis constructed from SUS304 stainless steel (SUS316 optional).

Plug-and-play USB Type-A interface, compatible with Windows, macOS, Linux, Android, and ARM-based systems.


Mechanical Features & Environmental adaptability

Panel board and keys material SUS304 Stainless-steel
Key press force 2 million min
Key press force 2~3N
Key travel length 0.6MM
Dimensions 352*140*21.5MM
Weight 3050g
Op. Temp -40℃~+65℃
Op. RH 10~95%
Storage temperature -40℃~+75℃
Storage RH 5~95%

Protection grade: IP67 / IK07

EMC Standards:

EN55022:1988+A1:2000+A2:2003

EN55024:1988+A1:2001+A2:2003

ESD protection: 15KV


Keyboard Language

Defult keyboard language is US.

Optional for customized different languages, such as Spanish, French, German, Portuguese, Italian, Russian, Arabic, Persian, etc.


Installation drawing

Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant 0

6.APPLICATION SITE

This fully-sealed keyboard is engineered for unsupervised or semi-supervised installations in public-access environments, including:

  • Information & Ticketing Kiosks​ – Airports, railway stations, bus terminals, shopping malls, hotels, universities

  • Self‑Service & Vending Systems​ – Ticket machines, fuel dispensers, parking pay stations, retail kiosks

  • Financial & Transaction Terminals​ – ATMs, cash deposit machines (CDMs), bank lobby terminals, public internet phones

  • Other High‑Traffic Public Areas​ – Hospitals, libraries, government offices, corporate lobbies, industrial gateways




7. more pictures:

Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant 1Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant 2Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant 3Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant 4Industrial Watertight Stainless Steel Keyboard with IP67 Sealed Touchpad – Full-Submersion Proof, Dustproof & Vandal-Resistant 5


8.Please note:

All photos on this website were taken in real conditions. Due to variations in lighting, shooting angles, and display resolutions, the images you see may exhibit a certain degree of color difference. We kindly ask you to refer to the actual received products for accurate representation. Thank you for your understanding.


If you have any question about this items,please feel free to contact us for further information,thank you.
