Industrial Stainless-Steel Keyboard With 2MM Key Travel Length Waterproof Keybord
Technical Specifications
Industrial front‑panel mount stainless steel keyboard with integrated 2‑key touchpad, engineered for seamless integration into kiosk and control panel facades.
Rated IP65 (dust‑tight and protected against water jets) and IK07 (high‑impact resistance) – built to withstand harsh environments, wash‑downs, and deliberate abuse.
Operates reliably from ‑40 °C, ensuring uninterrupted performance in freezing outdoor, refrigerated, or extreme‑climate settings.
Exceeds 2 million keystroke lifecycle for maintenance‑free operation in continuous, high‑traffic public applications.
Panel and keys constructed of SUS304 stainless steel (SUS316 optional) for superior corrosion, chemical, and weather resistance.
Plug‑and‑play USB Type‑A interface compatible with Windows, macOS, Linux, Android, and ARM‑based kiosk/control systems.
Mechanical Features & Environmental adaptability
| Panel board and keys material: SUS304 Stainless-steel |
| Base board material: Aluminum alloy |
|
| Key life cycle: 2million min. |
|
|
| Key press force: 2~3N |
|
|
| Key travel length: 2MM |
|
|
| Dimensions: 416*134*24MM |
|
|
| Weight: 1450g |
|
|
|
| Operating temperature: -40℃～+65℃, |
|
| Operating RH: 10～95% |
|
|
| Storage temperature: -40℃～+75℃ |
|
| Storage RH: 5～95% |
|
|
|
| Protection grade: IP65 / IK07 |
|
|
| EMC Standards: |
|
|
|
| EN55022:1988+A1:2000+A2:2003 |
|
| EN55024:1988+A1:2001+A2:2003 |
|
| ESD protection: 15KV |
|
|
|
Keyboard Language
Defult keyboard language is US.
Optional for customized different languages, such as Spanish, French, German, Portuguese, Italian, Russian, Arabic, Persian, etc.
Installation drawing
